Metal Hood & Housing Housings. surface mounting H32B-SF-2L-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36/2PG42
Product description
-
H32B-SF-2L-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36/2PG42
COLUMN:Hood & Housing series/32B Metal Hood & Housing POSITION:Housings PRODUCT MODEL:H32B-SF-2L-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36/2PG42 ORDER NUMBER:19300320232 PRODUCT CERTIFICATION:CQC CE ROHS
产品参数
表面处理 Surface Epoxy power paint/Chromated/nickeling 材料 Material zinc die-cast 颜色 Colour Grey
联锁元件 Locking element ---联锁方式 -Lever type Lever ---材料 -Material Metal Galvanized/nickel plating
密封元件 Hoods & Housings seal NBR 适用温度范围 Limiting temperatures -40℃...+125℃ 阻燃等级 Flammability acc. to UL 94 V0 防护等级 Degree of protection acc.to DIN EN 60 529 for coupled connector IP65
