Inserts Crimp Terminal HE-048-MC
Product description
-
HE-048-MC COLUMN：SOCKET SERIES >HE SERIES / Standard Connector POSITION：Male Inserts PRODUCT MODEL：HE-048-MC
ORDER NUMBER：09330242602 / 09330242612
PRODUCT CERTIFICATION：CQC CE ROHS
插芯Inserts Hoods/Housing：matching 48B Housing
接插件针数 Number Of Contacts 48 －额定电流 －Rated Current 16A
－相对额定电压 －Rated Voltage 500V －相间额定电压
－额定脉冲电压 －Rated Impulse Voltage 6KV －污染程度 －Pollution Degree 3 －或 －Or
－依据UL/CSA额定电压 －Rated Voltage Acc.to Ul CSA 600V 绝缘电阻 Insulation Resistance ≥1010Ω 材料 Material Polycarbonate 工作温度范围 Limiting Temperatures -40℃...+125℃ 依据UL94阻燃等级 Flammability Acc. To UL94 V0 可拔插次数 MecHEnical Working Life-mating Cycles ≥500 插针 材料 Material Copper 表面处理 Surface Silver plated/Gold plated 接触电阻 Contact Resistance ≤1mΩ 冷压连接
－导线规格 Wire Gauge 0.14-4mm? －AWG AWG 26-14 －拧紧力矩 Tightening Torque 0.5Nm
Hoods/Housing：>>48B Housing<<
