Pneumatic Module HMP-002

The current position is：Home >Products >Insert Series >HM Series / Modular Connector

Product description

	HMP-002
	COLUMN：HM SERIES / Hinged Frames
	POSITION：
	PRODUCT MODEL：HMP-002
	ORDER NUMBER：09140024501
	PRODUCT CERTIFICATION：CQC CE ROHS

插芯Inserts		Hoods/Housing：matching Housing
接插件针数	Number Of Contacts	2
－额定电流	－Rated Current
－相对额定电压	－Rated Voltage
－相间额定电压
－额定脉冲电压	－Rated Impulse Voltage	6KV
－污染程度	－Pollution Degree	3
－或	－Or
－依据UL/CSA额定电压	－Rated Voltage Acc.to Ul CSA	600V
绝缘电阻	Insulation Resistance	≥10¹⁰Ω
材料	Material	Delrin Acetal
工作温度范围	Limiting Temperatures	-40℃...+125℃
依据UL94阻燃等级	Flammability Acc. To UL94	V0
可拔插次数	MecHEnical Working Life-mating Cycles	≥500
插针
材料	Material	Copper Alloy
表面处理	Surface	Silver plated/Gold plated
接触电阻	Contact Resistance	≤3mΩ
冷压连接	Internal Diameter (id)	6.0mm/1/4"
－导线规格	Wire Gauge	0.09-0.52mm2
－AWG	AWG	28-20
－拧紧力矩	Tightening Torque
