Metal Hood & Housing Housings. surface mounting H48B-SF-1L-CV-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36

The current position is：Home >Products >Hood/Housing Series >48B Metal Hood/Housing Series

Product description

	H48B-SF-1L-CV-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36
	COLUMN：Hood & Housing series/48B Metal Hood & Housing
	POSITION:Housings
	PRODUCT MODEL：H48B-SF-1L-CV-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36
	ORDER NUMBER：193004802552
	PRODUCT CERTIFICATION：CQC CE ROHS

产品参数

表面处理	Surface	Epoxy power paint/Chromated/nickeling
材料	Material	zinc die-cast
颜色	Colour	Grey
联锁元件	Locking element
---联锁方式	-Lever type	Lever
---材料	-Material	Metal Galvanized/nickel plating
密封元件	Hoods & Housings seal	NBR
适用温度范围	Limiting temperatures	-40℃...+125℃
阻燃等级	Flammability acc. to UL 94	V0
防护等级	Degree of protection acc.to DIN EN 60 529 for coupled connector	IP65

Data download

H48B-SF-1L-CV-M32/2M32/M40/2M40/PG29/2PG29/PG36/2PG36
