Metal Hood & Housing Housings. cable to cable.high construction H6B-CCTH-1L-M25/PG21/PG29
Product description
-
H6B-CCTH-1L-M25/PG21/PG29
COLUMN:Hood & Housing series/6B Metal Hood & Housing POSITION:Housings PRODUCT MODEL:H6B-CCTH-1L-M25/PG21/PG29 ORDER NUMBER:19300060756 PRODUCT CERTIFICATION:CQC CE ROHS
产品参数
表面处理 Surface Epoxy power paint/Chromated/nickeling 材料 Material zinc die-cast 颜色 Colour Grey
联锁元件 Locking element ---联锁方式 -Lever type Lever ---材料 -Material Metal Galvanized/nickel plating
密封元件 Hoods & Housings seal NBR 适用温度范围 Limiting temperatures -40℃...+125℃ 阻燃等级 Flammability acc. to UL 94 V0 防护等级 Degree of protection acc.to DIN EN 60 529 for coupled connector IP65
Data download
